120m³/h Tunnel Boring System – Compact & Efficient Desanding Plant for Bored Pile, TBM, and HDD
Product Description
The 120m³/h Tunnel Boring System (Bored Pile & TBM Desanding Plant) is a cost-effective and compact mud-water separation solution designed for bored pile construction, tunnel boring machines (TBM), and horizontal directional drilling (HDD). Developed by TR Solids Control, this system is engineered to handle high-efficiency slurry treatment within a small footprint, making it ideal for projects with limited working space.
The plant adopts a multi-stage separation process, ensuring precise removal of solid particles across different size ranges. It enables water recycling, reduces slurry disposal costs, and supports environmentally responsible construction practices. The system can be configured flexibly for various installation requirements, offering both performance and versatility.
Features & Benefits
✔ Compact & Space-Saving Design – Perfect for job sites with limited working areas.
✔ Flexible Configuration – Adaptable for bored pile, TBM, or HDD mud recycling systems.
✔ Multi-Stage Separation – Efficiently removes solids of different sizes for optimal mud treatment.
✔ Water Recycling Capability – Reduces water consumption and environmental impact.
✔ Cost-Effective Operation – Lower unit mud treatment cost with high treatment efficiency.
Single module processing capacity
Maximum mud handling capacity | 120m³/h | Total power | 82.8kw |
Separation particle size for purification and desanding | D50=0.074mm | Maximum moisture content of the sieve | 30% |
Coarse shaker | TRDGS900 | Power | 2.2kw*2 |
Fine shaker | TRDG700 | Power | 1.94kw*2 |
Defrosting pump flow | 120m³/h | Motor power | 37kw |
Deslation pump flow | 120m³/h | Motor power | 37kw |
Desander cyclone | 12inch | The number of desander cyclones | 2 |
Desilter cyclone | 4inch | The number of desilter cyclones | 8 |
Dimension | 6.5m*2.5m*7m | Weight | 10t(about) |
Solid content< | 30% | Maximum specific gravity capable of treating sludge< | 1.25g/cm³(±0.1) |
Technical Advantages
✔ Self-Developed Multi-Layout System – Tailored to meet diverse slurry and sewage treatment needs.
✔ Optimized Performance – Each separation stage designed for maximum efficiency in its particle size range.
✔ Durable Build Quality – Resistant to wear and corrosion from abrasive construction slurries.
✔ Low Maintenance Requirement – Simplified structure with reliable components ensures stable long-term operation.
✔ Customizable Options – Configurable tank sizes, pump capacities, and separation stages to fit project demands.
Applications
✔ Bored Pile Construction
✔ Tunnel Boring Machines (TBM)
✔ Horizontal Directional Drilling (HDD)
✔ Slurry Shield Tunneling Projects
✔ Sewage & Slurry Treatment in Civil Construction
Advantages & Services
✔ Turnkey System Supply – Complete desanding plant with pumps, tanks, and separation units.
✔ Project-Specific Customization – Flexible design to match site requirements.
✔ Compliance with Industry Standards – Built according to ISO and construction safety regulations.
✔ After-Sales Support – Operator training, and quick spare parts supply.
✔ Global Service Network – Technical support available worldwide for construction projects.
Why Construction Professionals Choose 120m³/h Tunnel Boring System?
✔ Economical & Reliable – Provides efficient slurry treatment with low operating costs.
✔ Proven Versatility – Works seamlessly across bored pile, TBM, and HDD applications.
✔ Eco-Friendly Operation – Recycles water and minimizes construction waste.
✔ High Efficiency in Limited Space – Compact design without compromising performance.
✔ Trusted Manufacturer – Engineered by TR Solids Control, a leader in solids control and mud recycling technology.
About TR SolidsControl
TR SolidsControl is a professional manufacturer of drilling fluid
equipment, supplying advanced solids control solutions for oil and
gas, trenchless, and geothermal industries worldwide. Our
commitment to innovation and quality ensures high-performance
products and reliable service.
|
|
